Module parameter |
Operation Voltage |
5.0V |
Bus Timing |
8080 bus |
Bus median |
8-bit, 16-bit compatible parallel interface |
Structural parameters |
Outline(mm) |
186.1×101.2×15MAX |
VA(mm) |
154.08×86.58 |
TFT Parameters |
Size (inch) |
7 |
Technology Type |
a-si TFT |
Resolution |
480(RGB) x 234 |
Dot pitch |
0.321(H)x0.370(V) |
Color depth |
16 bits color |
Viewing Angle |
12 o’clock |
BL |
LED |
Luminance |
200 cd/m2 |
Contrast Ratio(Degree) |
300 |
NTSC |
50 |
Temperature Parameter |
Operation Voltage |
-20℃ ~+70℃ |
Storage Temperature |
-30℃ ~+80℃ |
