Module parameter |
Operation Voltage |
5.0V |
Bus Timing |
8080 bus |
Bus median |
8-bit, 16-bit compatible parallel interface |
Structural parameters |
Outline(mm) |
98.1×65.1×10.2MAX |
VA(mm) |
70.08(W) x 52.56(H) |
TFT Parameters |
Size (inch) |
3.5 |
Technology Type |
a-si TFT |
Resolution |
320×3RGB×240 |
Dot pitch |
0.00735(RGB)(W)×0.00735(H) |
Color depth |
16 bits color |
Viewing Angle |
12 o’clock |
BL |
LED |
Luminance |
200 cd/m2 |
Contrast Ratio(Degree) |
300 |
NTSC |
50 |
Temperature Parameter |
Operation Voltage |
-20℃ ~+70℃ |
Storage Temperature |
-30℃ ~+80℃ |
